Standard Included:
(1) RUiXU Lithi2-16
(1) RJ45/CAT5e Patch Cable(1) Ground Cable
(1) Set of parallel 1/0 AWG OP140 or PP140 cable
Lithi2-16
Nominal voltage ：51.2V
Nominal capacity@0.2C ：314 Ah
Min. capacity@0.2C：314 Ah
Nominal energy :16.07kWh
Dimension(H*W*D):924(with wheels)*543*250mm | 36.3(with wheels)*21.3*10inch
Weight: ~137kg （302.01lb)
Cycle life@80% DOD:≥9500 cycles
COMMUNICATIONS:
Canbus : Victron,SMA,Studer Innotec,Sofar,Solark,Solis,Goodwe,Deye,
Growatt,SAJ,LUXPOWER,Megarevo,INVT,Sermatec,TBB,
MUST,Sunsynk,Schneider
RS485 : MPP,Voltronic,RCT,Alpha outback
EXPANDABLE
Support 32pcs in parallel
expandable from 16kWh to 512kWh for both residential and commercial buildings.
IP55
Perfect for outdoor applications
This product is for both indoor or outdoor use. If installed outdoors, it is recommended to add arain shelter and a sunshade.
ON-BOARD LCD TOUCH SCREEN5-inch capacitive touch screen provides battery information and allows easy and intuitive adjustment of battery settings.
GAS AEROSOL FIREROOF MODULEGas Aerosol Fireroof module improves fire protection inside the battery pack to both electrical lines and cells.
QUICK PLUGSQuick plugs provide 250A (continuous) overcurrent capacity, easy tool-less connection, long-term anti-loosening and heating protection.
FUMA WHEELS AND WALL MOUNTED FIXATIONFour concealed heavy-duty Fuma wheels facilitate movement of the battery without detracting from the elegant design. An anti-tipping mount on the back anchors the battery to the wall.
BATTERY MAINTENACE AND INSPECTION PORTAn inspection port on the side of the battery provides access to the BMS and fuse for ease of maintenance.
ALL POLE PROTECTIONAll-pole, dual protection through fuse (negative terminal) and micro circuit breaker (positive terminal).
INTELLIGENT BALANCINGA double equilibrium approach achieves efficient cell balancing by calculating capacity differences between battery cells from charging-process data and by extending the balancing time, improving the efficiency and reliability compared to general passive and active balancing modes.
SELF-HEATING FEATUREKeeping your battery charged in cold temperatures .
ELECTRO-COATING BATTERY CASE FOR OUTDOOR USEElectro-coating (electrophoresis) of the battery enclosure provides excellent rust prevention for outdoor use.The electrophoretic coating process is widely used in the production of automotive body shells
Reviews
My friend got 6 EG4 rack batteries. After we installed the rack, batteries, communication, wireway etc..... I said to myself.... there is no way I'm going through all of this. I've been researching quite a few models for the past year and I found this to be the best and most durable since it's outdoor rated. I went with 2 of these which brings my capacity to 32KwH. I live in a very hurricane prone area so these are exactly what I need. Plug and Play, works with my new EG4 12kpv without issue
I picked up my Ruixu 16kWh battery today. It was really simple to set up and get working with my EG4 6000 XP. It took about an hour to get it unloaded out of the back of the truck (300+ lbs!), unboxed (heavy duty plywood crate), and connected in place of the other lithium batteries that were previously running my house.
Read reviews, specs and watched videos on many, many different battery platforms. I kept coming back to these.
They were shipped and received in about a week. Packaging is extremely good! They are super easy to setup (once in place….HEAVY!). Connected them to my 2 6000xp’s and gave them the initial charge. Have been running critical loads for a month and 470kWh of battery usage. Flawless operation. I’ve ordered a 3rd and will probably add a 4th soon as well! Battery setting 6 for these inverters
I was able to get my two Ruixu batteries connected pretty easily. I just set the inverter type to luxpower on the master battery and it all played nicely. I used the busbars that Ruixu made for these batteries. I still need to secure the batteries to the wall. This was my first solar project.
I have been running my system for about 7 months now with an NHX-12k inverter and 3 RUIXU Lithi2 batteries. I started with one battery and inverter. When I commissioned them it was pretty much plug and play with the inverter communication cable. All I had to do was set it to my inverters protocol and it simply worked right out of the gate. Adding batteries 2 & 3 we just as easy.
The system has run flawlessly. I will be adding 3 more batteries later this year. It's Best Bang for the Buck!
